Product Description

The VSX104 is a 300 MHz fanless CPU module featuring a complement of robust features such as extended temperature operation and soldered DDR2 RAM integrated in a small, low power package. The VSX104 is RoHS compliant and conforms to the PC/104 form factor, which allows users to easily add a wide range of low-cost I/O options.

The VSX104’s 300 MHz DM&P Vortex86SX System-on-Chip (SoC) is a high performance and fully static 32-bit x86 processor designed to work with embedded operating systems including Windows® CE, Linux, DOS, and most popular 32-bit RTOS. Standard features of the VSX104 include 128 MB soldered on DDR2 RAM, four COM ports, two USB 2.0 ports, and one 10/100 Ethernet port. In addition to 2 MB onboard SPI flash (floppy emulation), it also includes both a Type I CompactFlash™ socket as well as a microSD socket. An onboard redundancy port allows for two VSX14 modules to be stacked together, and system expansion is supported by the PC/104 interface.

The VSX104 is a compact design measuring 3.55" x 3.775" x 0.9" and has an operating temperature of -40 ºC to +85 ºC. Single +5 VDC power is supplied through the PC/104 bus or 2-position screw terminal and total power consumption is a mere 1.85 Watts

Full specifications, user manuals and other supporting information are available here
